72M ANCHOR HANDLING/ OFFSHORE SUPPORT VESSEL FOR SALE
72M ANCHOR HANDLING/ OFFSHORE SUPPORT VESSEL FOR SALE Built 2009
General Particular
Year Built : 2009 / Indonesia
Flag : Malaysian
Class : ABS
Notation: Maltase Cross+A1, FiFi 1 + DPS-2 + AMS , (Anchor Handling/ Offshore Support Vessel)
Dimensions
Length O.A. : 72.50M
Breadth Mould : 17.00 M
Depth Mould : 7.50 M
Designed Draft : 6.48 M
Gross Tonnage : 2921 Tons (approx.)
Net Tonnage : 876 Tons (approx.)
Free Deck Space : 502 sq. m. (approx.)
Deadweight : 2940 T
CARGO / TANK CAPACITY
Fresh Water Tank : 760.00 m3
Fresh/Drill Water/SWB Tank : 560.00 m3
Fuel Oil Tank : 1150.00 m3
Liquid Mud/Brine Water Tank : 720.00 m3
Hydraulic Oil Tank : 7.00 m3
Foam Tank : 21.00 m3
Dispersant : 21.00 m3
Dirty Oil Tank : 11.00 m3
Cement Tank : 10,800.00 cu. ft.
Lub Oil Storage Tank (M/E) : 14.00 m3
Lub Oil Storage Tank (G/set) 6.50 m3
72M ANCHOR HANDLING/ OFFSHORE SUPPORT VESSEL FOR SALE
DECK MACHINERY AND TOWING / ANCHOR HANDLING EQUIPMENT
Towing & Anchor handling Winch : Double Drum Waterfall type BRATVAAG
low pressure electro hydraulic operated
Towing /Working Drum Capacity : 2990 M x 82 mm dia each
Winch Load Capacity : 350 Tons @ 6m/min. at low speed 1st layer
Brake Holding : 450 Tons Brake Holding
Storage Reel Winch Capacity : 2 x 2990 m x 82 MM dia. @ electro
hydraulic system
Towing Pins : 2 sets x 500 Tons
Shark Jaw : 4 sets x 200 Tons Karmfork
Stern Roller : 5.500 M (L) x 2.50 M dia.
Anchor Windlass/Towing Winch : 1 x 14 Tons @ electro hydraulic system
Capstan : 2 x 10 Tons @ electro hydraulic system
Tugger Winch : 2 x 15 Tons @ electro hydraulic system
Provision Deck Crane : 1 x 10 Tons (8m) SWL @ Marine Type
NAVIGATION / COMMUNICATION EQUIPMENT
GMDSS Radio A3 : 1 complete set
GPS Navigator : 1 unit
Echo Sounder : 1 unit
Radar : 2 units
Gyro Compass c/w Autopilot : 3 units Gyro Compass with 1 unit Autopilot
Speed Log : 1 unit
Navtex Receiver : 1 unit
Automatic Identification System : 1 unit
EPIRB : 1 unit
SART 2 units
Ship Security Alarm System (SSAS) : 1 set
Dynamic Positioning System – 2 : 1 complete set
FIRE FIGHTING EQUIPMENT
External Fire Fighting system : FiFi 1 System @ 2 x 1200 cu. m/hr water
monitor c/w deck spray system to ABS rules
Internal : Complies to classification Society &
SOLAS requirement Speed Log : 1 unit
LIFE SAVING EQUIPMENT
Liferaft : 6 x 25 men
Lifebuoys : 10 nos.
Lifejackets : 60 nos. Lifejackets
Oxygen Resuscitator : 1 set
Rescue Boat 1 x FRC Type Rescue boat c/w launching
A-Frame
First Aid Kit : 4 x 25 men
Work Vest : 8 nos
Man Overboard Smoke : 2 pcs
Stretcher : 1 nos
Splints : 6 sets
Self Igniting Lights : 2 pcs
Pyrotechnics : 1 complete set
ACCOMMODATION
2 x 1-Man Cabins (2)
3 x 2-Men Cabins (6)
10 x 4-Men Cabins (40)
Total = 48 men
1 x 2-Berth (Sickbay)
Fully Air Conditioned
