60M DP2 AHTS NEW BUILD FOR SALE File-CH-0627
60M DP2 AHTS NEW BUILD FOR SALE
General Particular:
Year Build: New Build
Class: ABS
Class Notation ABS + A1(E), Offshore Support Vessel
(AH, TOW, Supply, FFV 1, OSR-C, SPS) + AMS, + DPS-2.
Principal Dimension
LOA 60.000 m
Length waterline 59.444 m
between perpendicular 55.593 m
Breadth moulded 15.800 m
Depth moulded 6.50 m
Draft moulded 5.10 m
Complement
4 x One(1)-Crew Cabins 4 men
6 x Two(2)-Crew Cabins 12 men
8 x Four(4)-SP Cabins 32 men
Total 48 men
1 x Hospital 1 man
Tankage
Fuel oil 585 m3
Fresh water 375 m3
Drill water/Water ballast 650 m3
Foam 14 m3
Detergent 14 m3
Mud/ Brine 355 m3
ORO 285 m3
Cement Tanks 4 x 42.5 m3
Performance
Deadweight 1500 Tonnes
Gross tonnage 1678 ~
Deck loading 7 Tonnes/m2
Clear deck area 400 m2
Trial speed 13.0 knots
Bollard Pull 80 Tonnes
60M DP2 AHTS NEW BUILD FOR SALE
Machinery
Main engine 2 x 3000 PS
Propulsion system Controllable pitch propeller
Generating set 3 x 450KW
diesel driven
Shaft Generator 2 x 1000KW main engine driven
Bow thruster 2 x 10.0T electric driven
Stern Thruster 1x 6.0T electric driven
Fuel oil cargo pump 2 x 150m3/hr @ 75m head
Fresh water cargo pump 1 x125m3/hr @ 75m head
Drill Water cargo pump 1 x 100m3/hr @ 75m head
Mud Pump 2 x 75m3/hr @ 75m head
Deck Machinery
Anchor handling/towing winch 1 x 150 tonnes line pull
Brake holding 250 tonnes
Tuggers 2 x 10 tonnes @ 15m/min
Capstan 2 x 5 tonnes @ 15m/min
Shark jaw & Towing pins 200 tonnes Hydraulic
operated type
Deck Crane 3 tonnes SWL @ 12M
Cold Room
Chiller 15m3 (approx)
Freezer 15m3 (approx)
